| Basic parameters | |
| Level: | Hardcore SUV |
| Engine: | 505kW |
| Power type: | Hybrid plugin |
| Comprehensive maximum power (kW): | 505 |
| Comprehensive maximum torque (Nm): | 760 |
| Transmission: | E-CVT |
| Length x width x height (mm): | 4890x1970x1920 |
| Body structure: | 5door 5seat SUV |
| Year of listing: | 2023 |
| Maximum speed (km/h): | 180 |
| Official 0-100km/h acceleration time (s): | 4.8 |
| WLTC comprehensive fuel consumption (L/100km): | 1.81 |
| Minimum State of Charge Fuel Consumption (L/100km): | 7.8 |
| Vehicle body parameters | |
| Wheelbase (mm): | 2800 |
| Curb weight (kg): | 2890 |
| Total mass of trailer (kg): | 2500 |
| Minimum ground clearance (mm): | 220 |
| Front wheelbase (mm): | 1660 |
| Rear wheelbase (mm): | 1660 |
| Approach angle (°): | 35 |
| Passing angle (°): | 20 |
| Departure angle (°): | 32 |
| Fuel tank volume (L): | 83 |
| Engine | |
| Displacement (L): | 1.5 |
| Displacement (mL): | 1497 |
| Air intake form: | Turbo |
| Cylinder arrangement: | Straight (L-shaped) |
| Number of cylinders: | 4 |
| Valve distribution mechanism: | DOHC |
| Cylinder head material: | Aluminum alloy |
| Material of cylinder body: | Aluminum alloy |
| Maximum horsepower (Ps): | 194 |
| Maximum power (kW): | 143 |
| Maximum torque (Nm): | 273 |
| Fuel: | Gasoline |
| Motor | |
| Motor type: | Permanent magnet/synchronous |
| Maximum power of electric motor (kW): | 485 |
| Maximum torque of electric motor (Nm): | 760 |
| Maximum power of front motor (kW): | 200 |
| Maximum torque of front motor (Nm): | 360 |
| Maximum power of rear motor (kW): | 285 |
| Maximum torque of rear motor (Nm): | 400 |
| Battery | |
| CLTC pure electric range (km): | 125 |
| WLTC comprehensive range (km): | 1200 |
| Battery energy (kWh): | 31.8kWh |
| Battery type: | Lithium iron phosphate battery |
|
|
