| Brand Name : | volkswagen |
| Model Number : | ID.4 X |
| Payment Terms : | T/T |
| Basic parameter | |
| manufacturer | SAIC Volkswagen |
| rank | Compact SUV |
| Energy type | Pure Electric |
| Time to market | 2024.01 |
| NEDC electric range (km) | - |
| WLTC electric range (km) | - |
| CLTC Electric Range (km) | 601 |
| Battery fast charge time (hours) | 0.67 |
| Battery slow charge time (hours) | 12.5 |
| Battery fast charge range (%) | 0-80 |
| Battery slow charge range (%) | 0-100 |
| Maximum power (kw) | 150 |
| Maximum torque (N·m) | 310 |
| Body structure | 5-door 5-seat SUV |
| Motor (Ps) | 204 |
| Length * Width * Height (mm) | 4612*1852*1640 |
| Official 0-100km/h acceleration (s) | - |
| Maximum speed (km/h) | 160 |
| Power equivalent fuel consumption (L/100Km) | 1.64 |
| Service weight (kg) | 2120 |
| Maximum load weight (kg) | 2580 |
| Body | |
| Length (mm) | 4612 |
| Width (mm) | 1852 |
| Height (mm) | 1640 |
| Wheelbase (mm) | 2765 |
| Front wheel base (mm) | 1587 |
| Rear wheel base (mm) | 1566 |
| Approach Angle (°) | 16 |
| Departure Angle (°) | 18 |
| Minimum turning radius (m) | - |
| Body structure | 5-door 5-seat SUV |
| Door opening mode | Flat open |
| Number of doors (each) | 5 |
| Number of seats (PCS) | 5 |
| Tank capacity (L) | - |
| Front trunk volume (L) | - |
| Trunk volume (L) | 484-1546 |
| motor | |
| Front motor brand | - |
| Rear motor brand | Volkswagen |
| Front motor type | - |
| Rear motor type | EBN |
| Motor type | Permanent magnet/synchronous |
| Total motor power (kw) | 150 |
| Total motor horsepower (PS) | 204 |
| Total motor torque (N m) | 310 |
| Maximum power of front motor (kw) | - |
| Maximum torque of front motor (N·m) | - |
| Maximum power of rear motor (kW) | 150 |
| Maximum torque of rear motor (N·m) | 310 |
| Number of driving motors | Single motor |
| Motor layout | Rear-mounted |
| Battery type | Ternary lithium battery |
| Cell brand | CATL |
| Battery specific technology | - |
| Battery cooling system | Liquid cooling |
| NEDC electric range (km) | - |
| WLTC electric range (km) | - |
| CLTC Electric Range (km) | 601 |
| WLTC Comprehensive Range (km) | - |
| CLTC Comprehensive Range (km) | - |
| Battery energy (kwh) | 80.2 |
| 100km power consumption (kWh/100km) | 14.5 |
| Three power system warranty | Eight years or 160,000 km |
| Fast charge function | Support |
| Battery fast charge time (hours) | 0.67 |
| Battery slow charge time (hour) | 12.5 |
| Battery fast charge range (%) | 0-80 |
| Battery slow charge range (%) | 0-100 |
| Position of the slow charge port | Right rear side of vehicle |
| Position of the fast charge interface | Right rear side of vehicle |
| Gearbox | |
| For short | Single-speed transmission for electric vehicles |
| Number of gears | 1 |
| Transmission type | Fixed tooth ratio gearbox |
| Chassis steering | |
| Driving mode | Rear-mounted, rear-wheel drive |
| Four-wheel drive form | - |
| Front suspension type | McPherson independent suspension |
| Rear suspension type | Five-link independent suspension |
| Assist type | Electric power steering |
| Car body structure | Load-bearing |
| Wheel braking | |
| Front brake type | Ventilated disc type |
| Rear brake type | Drum type |
| Parking brake type | Electronic parking brake |
| Front tire specification | 235/50 R20 |
| Rear tyre specification | 255/45 R20 |
| Spare gauge | None |
| Spare tire placement method | - |
| Passive safety | |
| Main/passenger airbags | Driver ●/Vice driver ● |
| Front/rear side airbags | Front ● /Rear - |
| Front/rear head bag (air curtain) | Front ● /Rear ● |
| Run-Flat Tire | ● |
| Active safety | |
| ABS anti-lock | ● |
| Braking force distribution (EBD/CBC, etc.) | ● |
| Brake assistance (EBA/BAS/BA, etc.) | ● |
| Traction control (ASR/TCS/TRC etc.) | ● |
| Body stability control (ESC/ESP/DSC etc.) | ● |
| Tire pressure monitoring function | ● Tire pressure alarm |
| Seat belt not fastened reminder | ● Whole car |
| ISOFIX child seat interface | ● |
| Lane departure warning system | ● |
| Active braking/active safety system | ● |
| Fatigue driving tips | ● |
| DOW open door warning | ● |
| Forward collision warning | ● |
| Rear collision warning | - |
| Low speed driving warning | ● |
| Road assistance call | ● |
| - | |
| Driving control | |
| Driving mode switching | ●Exercise ●Economics ●Standard/Comfort ●Customization/Personalization |
| Energy recovery system | ● |
| Automatic parking | ● |
| Uphill aid | ● |
| Descend gently on a steep slope | - |
| Driving hardware | |
| Front/rear parking radar | Front ● /Rear ● |
| Driver assistance image | ● 360 degree panoramic images |
| Forward awareness camera | ● monocular |
| Number of cameras | ● 5 |
| Ultrasonic radar number | ● 12 |
| Number of millimeter wave radars | ● 3 |
| Driving function | |
| Cruise control system | ● Full-speed adaptive cruise control |
| Driver assistance system | ● IQ. Drive |
| Driver assistance class | ● L2 |
| Reverse side warning system | ● |
| Satellite navigation system | ● |
| Navigation traffic information display | ● |
| Parallel auxiliary | ● |
| Lane keeping assist system | ● |
| Keep lane centered | ● |
| Road traffic sign recognition | ● |
| Automatic parking | ● |
| Remote control parking | ● |
| Automatic lane change assistance | ● |
| Appearance/Anti-theft | |
| Pulley material | ● Aluminium alloy |
| Electric suction door | - |
| Frameless design door | - |
| Electric trunk | ● |
| Electric trunk location memory | ● |
| ● | |
| Car central control lock | ● |
| Key type | ●Remote key |
| Keyless activation system | ● |
| Keyless access function | ● Front row |
| Active closed intake grille | ● |
| Remote startup function | ● |
| Battery preheating | ● |
| External discharge | - |
| Induction trunk | ● |
| Outside light | |
| Low beam light source | ● LED |
| High beam light source | ● LED |
| Lighting features | ● Matrix |
| LED daytime running lights | ● |
| Adaptive near and far light | ● |
| Automatic headlight | ● |
| Steering auxiliary light | - |
| Front fog lights | - |
| ● | |
| Headlight height adjustable | ● |
| Headlights turn off late | ● |
| Skylight/Glass | |
| Skylight type | ● Cannot open panoramic sunroof ○ Openable panoramic sunroof |
| Front/rear power Windows | Front ● /Rear ● |
| Window one key lift function | ● Whole vehicle |
| Window anti-clamping function | ● |
| Rear side privacy glass | - |
| Car mirror | ● Driver+Light ● Vice driver+Light |
| Rear wiper | ● |
| Sensor wiper function | ● Rain sensor |
| Exterior rear-view mirror | |
| Exterior rearview mirror function | ●Electric adjustment ●Electric folding ●Rearview mirror heating ● Rearview Mirror memory ● Automatic folding when reversing ●Lock the car and fold it automatically |
| Screen/System | |
| Central control color screen | ● Touch LCD screen |
| Center control screen size | ● 12 inches |
| Central control screen type | ● LCD |
| Center control screen resolution | ● 1920x860 |
| Center screen pixel density | - |
| Bluetooth/car phone | ● |
| Sunflower Rotating Screen | - |
| Mobile interconnection/mapping | ● Support CarPlay ● Factory interconnection/mapping ● Support CarLife |
| Speech recognition control system | ● Multimedia system ● Navigation ● Telephone ● Air conditioning |
| Voice assistant wake word | ● Hello, Dazhong |
| Voice-free wake-up words | ● |
| Voice region wake recognition | ● Single Region |
| Continuous speech recognition | ● |
| Visible to say | - |
| Facial recognition | - |
| Voiceprint recognition | - |
| App store | ● |
| Vehicle intelligent system | ● MOS |
| Intelligent configuration | |
| Internet of Vehicles | ● |
| 4G/5G network | ● 4G |
| OTA upgrade | ● |
| Wi Fi hotspot | - |
| Remote function of mobile APP | ● Charging management ● Air conditioning control ● Vehicle condition query/diagnosis ● Vehicle location/car search ● Owner service (find charging piles, gas stations, parking lots, etc.) ● Maintenance/repair reservation |
| Car KTV | - |
| Steering wheel/Inside mirror | |
| Steering wheel material | ● Cortex |
| Steering wheel position adjustment | ● Manual up and down + front and rear adjustment |
| Shift pattern | ● Instrument panel integrated gear shift |
| Multi-functional steering wheel | ● |
| Steering wheel shift | - |
| Steering wheel heating | ● |
| Steering wheel memory | - |
| Driving computer display screen | ● Color |
| Full LCD dashboard | ● |
| Liquid crystal meter dimensions | ● 5.3 inches |
| Dashboard screen material | ● LCD |
| Dashboard screen resolution | ● 860x480 |
| AR-HUD augmented reality head-up display | ○ |
| HUD heads-up digital display | - |
| HUD head-up size | - |
| Internal rearview mirror function | ● Automatic anti-glare |
| ETC device | ○ |
| In-car charging | |
| Multimedia/charging interface | ● Type-C |
| USB/Type-C Specifies the number of ports | - |
| USB/Type-C Maximum charging power | ● 45W |
| Mobile phone wireless charging function | ● Front row |
| Mobile phone wireless charging power | - |
| Luggage compartment 12V power interface | ● |
| Seat configuration | |
| Seat material | ● Imitation leather |
| Sports style seat | - |
| Main seat adjustment mode | ● Front and rear adjustment ● Backrest adjustment ● Height adjustment (4 way) ● Lumbar support (4 way) |
| Auxiliary seat adjustment mode | ● Front and rear adjustment ● Backrest adjustment ● Height adjustment (4 way) ● Lumbar support (4 way) |
| Main/passenger seat electric regulation | Driver ●/Vice driver ● |
| Front seat function | ● Heating ● Massage |
| Power seat memory function | ● Driver's seat ● Vice driver's seat |
| Rear seat reclining form | ●Ratio folding |
| Front/rear center armrests | Front ● /Rear ● |
| Rear cup holder | ● |
| Audio/interior lighting | |
| Loudspeaker brand name | ○ Harman/Kardon |
| Number of speakers | ● 7 speakers ○ 10 speakers |
| Dolby Atmos | - |
| Interior ambient light | ● 30 colors |
| Touch reading light | ● |
| Air conditioning/Refrigerator | |
| Air conditioner temperature control mode | ● Automatic air conditioning |
| Heat pump air conditioning | - |
| Independent rear air conditioning | - |
| Backseat air outlet | ● |
| Temperature zone control | ● |
| Car air purifier | ● |
| PM2.5 filter device in car | ● |
| Anion generator | - |
| Air quality monitoring | ● |
|
|
